Cor Vision vs. Cor Vision Plus: Which Cortizo Sliding Door is Right for Your Project?
The Cortizo Cor Vision series represents the pinnacle of slimline architectural glazing, designed to maximize light and minimize frame. Both the Cor Vision and the Cor Vision Plus offer stunning 20mm–25mm sightlines, but they are engineered to meet fundamentally different project requirements.
Choosing the right system comes down to three key technical factors: size, thermal performance, and automation.
Here is a technical comparison to help you determine which model provides the ideal balance of aesthetics and performance for your build.
Technical Comparison At a Glance
1. The Critical Difference: Size and Weight Capacity
The primary differentiator between the two systems is the sheer scale they can achieve.
Cor Vision (The Minimalist Standard): This system is perfect for projects requiring a standard large opening. Its panels go up to approximately 3 meters high and can handle sashes up to 400 kg. This is more than sufficient for replacing standard patio doors or glazing most new extensions. Crucially, it maintains the absolute slimmest 20mm sightline.
Cor Vision Plus (The Oversized Specialist): This is the system for ambitious, grand-scale architecture. It is engineered to handle oversized panels reaching up to 4 meters in height and width—truly replacing an entire wall. To manage this massive scale, the interlock sightline is slightly increased to 25mm, providing the necessary structural strength.
The Verdict on Size:
If your design requires the absolute slimmest frame (20mm) and panels up to 3m high, choose Cor Vision.
If your vision requires a monumental glass wall up to 4m high and the slight frame increase is acceptable, choose Cor Vision Plus.
2. Thermal Performance: Double vs. Triple Glazing
The glazing capacity directly impacts a system’s thermal performance (measured by the Uw value).
Cor Vision: This model supports double glazing up to 30mm thick. This offers excellent insulation for a slimline system, often achieving Uw values around 1.3 W/(m2K). This is highly efficient for most UK and European residential projects.
Cor Vision Plus: The wider, stronger sash is designed to accommodate triple glazing packages up to 54mm thick. This is key for achieving Passivhaus-level or extremely low-energy performance, with Uw values dropping as low as 0.9 W/(m2K). This superior insulation also dramatically improves acoustic dampening.
The Verdict on Thermal Performance:
For excellent energy performance with a standard budget, Cor Vision is highly effective.
For the best possible insulation, superior noise reduction, or where building regulations demand extremely low Uw values, Cor Vision Plus is mandatory.
3. Operation and Automation: Manual vs. Motorised
Moving large glass panels smoothly requires sophisticated engineering, and at the Plus level, automation becomes a necessity.
Cor Vision: This is strictly a manual system, engineered for smooth operation up to its 400 kg limit.
Cor Vision Plus: While it can be operated manually up to 400 kg, the Plus system is designed with a hidden, high-capacity motorised option to handle panels weighing up to a staggering 700 kg. This feature is ideal for convenience, accessibility, and integrating with modern smart home systems, especially for the largest 4m×4mpanels.
The Verdict on Operation:
For standard use and manual control, Cor Vision is efficient and simple.
For the convenience of automation or for any panel exceeding 400 kg, Cor Vision Plus is the only choice.
Conclusion: Matching the System to the Vision
Both Cortizo systems deliver the ultimate slimline aesthetic. The choice rests entirely on the scale and performancedemands of your project:
Ready to determine the exact specifications for your build? Contact our technical team to discuss your panel sizes and desired thermal ratings to ensure you select the perfect Cortizo system.
The Engineering of Effortless Operation: What Makes a High-End Sliding Door Slide So Smoothly?
The most striking feature of a slimline sliding door system like the Cortizo Cor Vision is the sheer scale of the glass. These panels can be massive—often hundreds of kilograms each—yet they glide open with a mere touch, feeling almost weightless.
This effortless operation is not magic; it’s a direct result of meticulous engineering focused on three critical, often-unseen components: the rollers, the track, and the structural design.
Here is a deep dive into the hidden mechanics that ensure a large glass wall moves with the precision of a Swiss watch.
1. The Foundation: High-Performance Roller Assemblies
The roller system is the heart of the smooth operation. In a high-end slider, these are not simply small wheels; they are complex, multi-component assemblies designed to handle tremendous loads.
Load-Bearing Capacity: High-end rollers are precision-engineered to accommodate heavy weights, often rated to safely support panels of 300 kg, 400 kg, or more. They use durable materials, typically stainless steel or high-grade polymers, to prevent deformation or wear over time.
Tandem Roller Design: Many top-tier systems use tandem rollers—multiple wheels per assembly—to distribute the panel’s weight evenly across the track. This prevents any single point from bearing excessive stress, ensuring longevity and consistent movement.
Precision Bearings: The secret to the gliding motion lies in the bearings. Premium rollers feature precision ball bearings (often sealed for protection against dust and moisture). These components significantly reduce friction, allowing the massive panel to be moved with minimal force.
2. The Path: The Track System and Drainage
The track is the crucial path the rollers follow. A low-quality track will quickly lead to sticking, grinding, and failure. A premium system is designed for both precision and maintenance.
Corrosion-Resistant Materials: Since sliding tracks are often exposed to moisture, they must be highly resistant to corrosion. Tracks are typically constructed from hardened stainless steel or robust aluminium.
Recessed and Flush Design: For a seamless aesthetic, modern tracks are often installed flush with the interior floor. This requires a sophisticated design that still manages water. High-end systems include integrated drainage channels to efficiently divert rainwater away, preventing standing water that could compromise the rollers or the surrounding floor structure.
Self-Centering and Alignment: The track profile is designed to ensure the rollers remain perfectly centred. This precise guidance prevents any side-to-side wobble or rubbing, which is critical for maintaining the tight seals and the door’s effortless feel.
3. Structural Rigidity and Panel Guidance
The structural integrity of the frame and the glass panel itself plays a vital role in smooth operation.
Non-Flexing Profiles: When a large, heavy panel is pushed or pulled, the aluminium profile must not flex or twist. High-quality systems use engineered, multi-chambered profiles that provide exceptional rigidity. Flexing would cause the panel to bind in the track, instantly ruining the “effortless” experience.
Integrated Handling: The handles themselves are part of the engineering solution. Systems like the Cor Vision often feature a streamlined, integrated handle mechanism. This design ensures that the force exerted by the user is applied directly and optimally to initiate movement, rather than being applied to an external handle that might twist the frame slightly.
Precision Manufacturing Tolerances: High-end door manufacturers work within exceptionally tight manufacturing tolerances. This ensures that every panel is perfectly square, every roller housing is precisely aligned, and the gap between the interlock profiles is exact (e.g., the 20mm sightline). This precision guarantees that when the panel moves, it follows a true, straight line.
The Result: A Door That Glides
When premium components—low-friction tandem rollers, corrosion-resistant flush tracks, and highly rigid aluminium profiles—are precision-engineered together, the result is the ultimate user experience.
The door doesn’t slide; it glides. It’s a testament to the fact that in architectural glazing, the unseen engineering details are often the most important features, providing you with years of beautiful, maintenance-friendly, and truly effortless operation.
Planning your next glazed opening? Let us walk you through the technical specifications and operational feel of our high-end sliding door systems.
Sliding Door Security: Peace of Mind with the Cor Vision’s Integrated Locking System.
